ALUMINUM - all types.
-
5052  - 6061  - 6063  -7075  being the most popular.

We offer full milling, drilling, reaming, boring, threading, some bending, helicoil
inserting, install hardware, plating, heat treating, painting, and engraving.
Welding on a case by case basis.

    flat bar sizes:
         .062  inch x .062 inch thru 8.0 inch x 8.0 inch, up to 29.0 inches long.
         in some cases we can handle longer lengths, depending on product requirements.

    flat plate:
       up to 15.0 inches wide x 29.0 inches long x .032 inch thick thru 6.0 inches thick.
       in some cases we can handle larger sizes, depending on product requirements.

    rounds:
       .062 inch diameters thru 6.0 inches diameter, up to 36.0 inches long,
       including tubes.

    sheet:
       up to 48.0 inches x 48.0 inches, .032 inch thick to .250 inch thick.

    extrusions and castings:
       most any shapes, including heat sink applications, angles,
       u-shaped channels, etc.

    blocks:
       up to 12.0 inches x 12.0 inches x 12.0 inches, some limitations.
Future Machine's diversified customer base has given us the opportunity to work with many different types of
materials and products. Our combination of cnc milling machines, manual  machines, cad/cam software and other
equipment makes this task a lot easier. Our commitment to getting it right the first time means we make sure everything
we supply to our customers fits our equipment's capabilities and  capacity. We match our tools to your requirements.
Future machine offers a full line of cnc milling, manual milling, lathe turning, drilling, reaming, boring,
grinding, threading, plating, heat treating, electro polishing, passivating, engraving and painting in many
different types of materials. We can do assemblies.  We can install a variety of inserts into a wide range of
materials, including many composite materials. We can have parts welded, soldered, or brazed. We also work
on customer supplied materials. We can build fixtures and tooling. We do prototypes as well as large and small
quantity production.

    Below is a listing of the types and sizes of materials we work on and services and products we offer.
    Feel free to contact us if you would like to inquire about something you see here or something you feel we
can help you with, that might not be shown. We have tried to include as much as possible. All materials and
processes come with complete certification and verification, upon request.
If your products require Heat Treating or Brazing, before or after machining, we can take care of it. You can rest
assured that these processes will be performed to very rigid standards.  We use only
NADCAP accredited heat
treaters and brazers. A complete line of processes is available. Full certification is available. Future Machine requires
certification for these processes even if certification is not required by our customers.
STAINLESS STEELS- most types.
-
303 -304 -316 -410 -416 -440c being the most popular.

CARBON STEELS - most types.
-
1018 -A2 -D2 -01 being the most popular.

We offer full milling, lathe turning, drilling, reaming, boring, threading, some bending, helicoil
inserting, install hardware, electro polishing, heat treating, grinding,  passivation and engraving.
Welding on a case by case basis.

    flat bar sizes:
       .062  inch x .062 inch thru 4.0 inch x 4.0 inch, up to 29.0 inches long.
       in some cases we can handle longer lengths, depending on product requirements.

    flat plate:
       up to 15.0 inches wide x 29.0 inches long
       .032 inch thick thru 2.0 inches thick.
       in some cases we can handle larger sizes,
       depending on product requirements.

    rounds:
       .062 inch diameters thru 3.0 inches diameter, up to 12.0 inches long.
       including tubes.

    sheet:
       up to 48.0 inches x 48.0 inches, .032 inch thick to .250 inch thick.

    angles, shapes and castings:
       case by case

    blocks:
       up to 6.0 inches x 6.0 inches x 6.0 inches.
COMPOSITE MATERIALS:

We offer full milling, lathe turning, drilling, boring, threading, reaming, install inserts,
assembling, heat treating and in some cases special coatings.
TITANIUM and SUPER ALLOYS:
very limited-call or contact us
BRASS: -all types
-alloy 360 and -alloy 464 being the most popular.

BRONZE:
-alloy CA932 bearing bronze. -CA510 phosphor bronze

COPPER:
-alloy 101  -alloy 110  being the most popular.
we make a lot of heat sinks and bus bars with this material.


We offer full milling, lathe turning, drilling, reaming, boring,
threading,
some bending, brazing (limited), helicoil inserting,
install hardware,  plating and engraving.

    flat bar sizes:
       .062  inch x .062 inch thru 4.0 inch x 4.0 inch, up to 29.0 inches long.
       in some cases we can handle longer lengths, depending on product
       requirements.

    flat plate:
       up to 15.0 inches wide x 29.0 inches long x .032 inch thick thru 4.0
       inches thick. in some cases we can handle larger sizes, depending
       on product requirements.

    rounds:
       .062 inch diameters thru 4.0 inches diameter, up to 10.0 inches long.
       including tubes.

    sheet:
       up to 48.0 inches x 48.0 inches, .032 inch thick to .250 inch thick.

    castings:
       case by case.

    blocks:
       up to 12.0 inches x 12.0 inches x 12.0 inches, on a case by case basis.
  Future Machine offers a wide variety of platings, coatings, painting and
passivating. Again we won't list every process available, as it would be too long.
We will list the most common processes we can have done or handle for you. If a
process is not on the list, it doesn't mean we can't get it done. Feel free to

contact us about any of your plating, coating, passivating or painting
requirements.

PLATING:

    Chem Film  - all classes  gold, clear
    Anodize:
       type II - clear, black, gold, red, blue, grey. custom colors upon request.
       type III - clear, black.
    Nickel:  grade a thru g, -bright, -satin, RoHS Compliant.
    Electroless Nickel - class 1 thru 4 - grade a thru c, RoHS Compliant.
    Zinc -type 1 thru 4 - class sc1 thru sc4, gold, clear
    Tin -bright -satin
    Black Oxide
    Precious Metals
    and many more.
                  Also full masking and plugging to your specifications.

PAINTING:

    Enamel - most all colors, textured or non textured.
    Silk Screening - some limitations.
    Powder Coating - some limitations.

FINAL and SECONDARY FINISHING:

    Electro Polish -active -nonactive
    Passivation -type II, VI, VII, VIII
    Bead Blasting - coarse - fine. Some size limitations.
    Tumbling -deburr -even out surface finish -some stripping. Size limitations
.......Look no further for your VME, PMC, PCI, cPCI or Dot 10 type panels. At
Future Machine we can satisfy your demands for these panel products.
Our many years of experience with this product means we can offer fully
machined or punched VME, PMC, PCI, cPCI and Dot 10 type panels in the
configurations you need.
Silk screen is available. Composite material
panels are also available upon request.

Send us your configurations and we will do the rest.
Your satisfaction is our #1 priority.




We look forward to your business.
.     Rather than a list of every composite material we could work on, a list of the most
common composite materials that we have worked on and do work on would be best.
Also we are not going to list any minimum or maximum sizes.  As composites can
come in different forms and have characteristics that may restrict our ability to match
them to our equipment. So we do a lot of  the more exotic composite materials on a
case by case basis.


This list includes, but is not limited to:

       -delrin   -acytal
       -nylon -rulon  -teflon  -torlon -vespel
       -acrylic  -plexiglass  -polycarbonates -pvc
       -peek
       -garolite xx
       -phenolic
       -polyetherimide (ultem 1000)


Our policy is not to run any fiber-glass or fiber-glass based
products in our equipment.
Or any other materials that may damage the equipment
during the machining process.
All of our platers, painters or passivators will, upon request, provide complete certifications for all processes
performed. If you have special requirements we will work with you to meet those requirements whenever possible.
The most common processes we can have done or handle for you are:
all images and content copyright future machine 1997-2015©
.    We will not list each and every process that can be done, again the list would be too long. If a process
you require is not listed, it does not mean we cant have it done for you.
Contact us and we will provide
you with the help you need to meet your specifications.


    Some of the most common processes we can have done for you are:
HEAT TREATING:
    Annealing -all materials/processes applicable.
    Hardening -all materials/processes applicable.
    Normalizing -all materials/processes applicable.
    Aging -all materials/processes applicable.

BRAZING:
    -Vacuum -Torch
    -Silver

and much more available. Contact us for a complete description of processes available.
At Future Machine we can handle many of your assembly needs. We do simple hardware installation as well as
complete machined multi-part assemblies. The examples shown here represent typical assembly configurations that
were designed and manufactured by Future Machine to specifications requested by our customers. Features include
locating pins, bushings and bearings, pins that allow trouble free disassembly and reassembly, threaded and
non-threaded inserts for extra stability in composite materials as well as movable or mechanical assemblies.
Limitations on what we will assemble, are determined by our ability to inspect and verify that the assemblies meet the
specified requirements. Feel free to
contact us with any of your assembly needs, your satisfaction is our #1 goal.
NTDS / ATDS Interface Housing.
4 piece, complete machined
alloy, plated, engraved,
assembled. Delivered to
customer ready for further
assembly.
Power Supply Adapter Plates.
7 piece, composite, aluminum and
brass, machined complete, 14
inserts installed, plated,
assembled. Shipped to customer
ready for further assembly.
Slide Rod/Saw Assembly Kit.
22 piece, 1018 steel, Brass,
Bronze, Stainless Steel,
Aluminum, all parts machined
complete, plated, heat treated,
electro polished, assembled.
Delivered to customer ready for
further assembly.
ASSEMBLY:
SPECIALITY PRODUCTS:
